    Building MaterialsAZM150+/-20 Aluzinc Steel Coil 55% Aluminum 43.5% Zinc 1.5% Si Galvalume SteelAfp Az30 Regular Spangle

    Ask Lasest Price
    Brand Name : DECHO
    Model Number : ASTM A792M CS-B
    Certification : ISO 9001:2015 Certificate
    Price : 750~850 USD
    Payment Terms : L/C, T/T
    Supply Ability : 1000 tons per day
    Delivery Time : 30~45 days
    • Product Details
    • Company Profile

    Building MaterialsAZM150+/-20 Aluzinc Steel Coil 55% Aluminum 43.5% Zinc 1.5% Si Galvalume SteelAfp Az30 Regular Spangle

    Building MaterialsAZM150+/-20 Aluzinc Steel Coil 55% Aluminum 43.5% Zinc 1.5% Si Galvalume SteelAfp Az30 Regular Spangle


    Galvalume Steel Coil(55% Aluminium-Zinc Alloy Coated Steel Coil)

    Aluminium-zinc steel is composed of an aluminium-zinc alloy structure, consisting of 55% aluminium, 43.4% zinc and 1.6% silicon solidified at a high temperature of 600 degrees Celsius. Its entire structure consists of aluminium - iron - silicon - zinc, the formation of dense tetrameric crystals of an alloy coated steel.


    Main advantages

    1, smooth surface, excellent resistance to atmospheric corrosion, its corrosion resistance life is 2-6 times higher than hot-dip galvanised steel;

    2, with good heat and oxidation resistance, it does not change colour for a long time under 300℃, and it can be used for a long time around 500℃. In addition, the heat reflectivity of the product is higher than 75%, which is 2 times higher than that of galvanised sheet;

    3, has excellent paintability and good processing performance. The combination of machine material is strong, which is the best choice for colour coated steel sheet substrate. Its processability and weldability are similar to that of hot galvanised sheet, and it can be processed by cold bending and stamping, and has a good appearance.

    Applications

    Galvalume steel's superior protective characteristics and economical price make it ideal for :

    • Residential and commercial exterior building materials
    • Decking
    • Cladding
    • Cabinetmaking
    Tipps
    Storage: The product should be stored in a ventilated and dry place such as indoor, warehouse, etc. It should not be placed in an acidic environment for a long time. Outdoor storage should avoid rain to avoid condensation causing oxidation and discolouration.
    Transportation: Avoid external impacts, the means of transport must support the steel coils, reduce stacking, and take effective measures against rain.
    Processing: Use the same lubricant for cutting as for aluminium sheets. When drilling or cutting aluminium galvanised steel sheets, loose iron filings should be removed promptly.
    Difference between GI and GL
    The difference between galvanised steel and aluminium-zinc steel mainly lies in the different coating, the surface of galvanised sheet is evenly distributed with a layer of zinc material, the parent material plays the role of anodic protection, that is to say, the alternative corrosion of the zinc material protects the use of the parent material, and only when the zinc is all corroded to harm the parent material inside.

    European Standards EN 10346:2015

    StandardsSteel gradeThickness(mm)Width(mm)Coating Mass
    (g/square meter)
    EN 10346DX51D,
    DX52D,
    DX53D,
    DX54D,
    S220GD,
    S250GD,
    S280GD,
    S320GD,
    S350GD
    S550GD
    0.2 - 1.2800 - 1,250AZ100
    AZ150
    AZ185

    America standards ASTM A792M

    StandardsSteel gradeThickness(mm)Width(mm)Coating(g/square meter)
    ASTM A792MCS(TYPE A, B, C)
    FS(TYPE A, B)
    DS
    DDS
    SS GRADE
    33(230)
    37(255)
    40(275)
    50(340) CLASS 1~3
    80(550) CLASS 1~3
    0.2 - 1.2800 - 1,250AZM100
    AZM110
    AZM120
    AZM150
    AZM165
    AZM180

    Japanese Standard JIS G 3321

    StandardsSteel gradeThickness(mm)Width(mm)Coating(g/square meter)
    JIS G 3321SGLCC
    SGLCD
    SGLCDD
    SGLC400
    SGLC440
    SGLC490
    SGLC570
    0.2 - 1.2800 - 1,250Z06(60)
    Z08(80)
    Z10(100)
    Z12(120)
    Z14(140)
    Z18(180)
    Z20(200)
    Z22(220)
    Z25(250)
    Z27(270)

    Australian Standard AS1397

    StandardsSteel gradeThickness(mm)Width(mm)Coating
    AS1397G1~G3
    G250
    G300
    G350
    G450
    G500
    G550
    0.2 - 1.2800 - 1,250AZ150
    AZ200

    Product Description

    Thickness0.12-4.0mm
    Width914mm/1000mm/1200mm/1219mm/1220mm/1250mm/1500mm etc.
    Zinc Coating30-275gsm
    Coil weight3-8 tons or as customer's requirement
    Coil ID.506-610mm
    GradeSGCC,DX51D,DX53D,DX54D.Q195,Q235,Q345,etc
    Type of coatingGalvanized
    Technical StandardGBT2518-2008,ASTM A653, JIS G3302-1998,EN 10142-2000
    Trade terms
    Price termsEX-Work,FOB,CFR,CIF
    Payment termsT/T,L/C,Western Union
    AdvantageExcellent price, competitive price, prime quality, prompt delivery
    Delivery timePrompt delivery or as the order quantity
    Packaging Details
    Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement
    ApplicationWorkshop, agricultural, warehouse, corrugated roof sheet, wall, light steel roof structure, etc.
