1. Brief introductionIt is galvanized steel sheet with zinc and aluminum, and is the
ideal combination of anti-corrosion and alkali-resistance of zinc,
and the durability, heat-resistance, and acid-resistance of
aluminum.The galvanized layer
is consisted of 55% of aluminum and 43.3% of zinc and 1.6% of
silicon per weight
2. Steel coil processing
Entry end-twin decolier-cleaning-entry
looper-pretreatment-pretreatment oven-prime coater-prime
oven-quench unit-finish coater-finish oven-embosse-quench
unit-quench unit-exit looper-shear-coiler-exit end3. Application1) Construction: Roofing, cladding, structural sections, composite
panels
2) Electric appliance: Washing machine, refrigerators, toaster,
microwave
3) Miscellaneous: Air duct, lighting, computer casing
4. Features1) Formable, weldable and paintable
2) Superior long term corrosion resistance in the most atmospheric
conditions. This is achieved
through the combination of the sacrificial protection of the zinc
and barrier protection of aluminum
3) Hot dip galvalume coating out-perform galvanized coating from
2-6 times than galvanized steel
5. Packing detailsEach hot dip galvalumetube wrapped by plastic film and waterproof
paper, one steel strip strapping
on the galvalume steel coil circumference. 3 - 5 coils tube packed
eye vertical on wood pallet, and
strongly strapped by edge protection, and at least 4 steel straps
through coil eye. Coil tube packed
eye to sky on wood pallet
Surface Treatment | Galvalume Steel Coil |
Chemical Treatment | minimize the chance of humid-storage staining forms a dark gray
surface discoloration on the surface |
retain the bright metallic luster for a long period |
Oil | minimize the tendency for humid-storage stain |
Chemical Treatment and Oil | chemical treatment provides very good protection against
humid-storage staining, while the oil provides lubricity for operations. |
Dry | must be transported and stored with special precautions to preserve
low-humidity conditions. |
Anti-finger print | minimize the chance of humid-storage staining forms a dark gray surface discoloration on the surface |
