    HDGI Regular Spangle Z120 / Z225 0.40mm 1200mm Corrugated Sheet And Metal Tile Chromated Unoiled Non Skin Pass AFP

    Ask Lasest Price
    Brand Name : Decho
    Model Number : Hot dip galvanised steel
    Certification : ISO 9001
    Price : 650~800USD
    Payment Terms : L/C, T/T
    Supply Ability : 800 tons/ day
    Delivery Time : 30~45days
    • Product Details
    • Company Profile

    HDGI Regular Spangle Z120 / Z225 0.40mm 1200mm Corrugated Sheet And Metal Tile Chromated Unoiled Non Skin Pass AFP

    HDGI Regular Spangle Z120 / Z225 0.40mm 1200mm Corrugated Sheet And Metal Tile Chromated Unoiled Non Skin Pass AFP

    Surface structure of hot dip galvanized steel sheet and coil

    Surface structureCode No.FeaturesApplication
    Conventional spangleZSpangles condensated on zinc coating
    under normal conditions after galvanizing.
    Commercial purposes
    Small spangleXSurface in spangles smaller than
    conventional ones and due to controlled
    condensation of zinc coating.
    Applications where conventional
    spangles cannot meet the surface
    appearance requirements.
    Skin passed spangleGSurface structure after special skin
    pass treatment.
    Applications of high surface
    quality requirements, such as
    color coating base plates.
    Skin passed small spangleGX--
    Zero spangleNNo visible spangles on coating surface
    as a result of a special production process.
    -
    Zn-Fe alloyRNo spangle, gray, normally matterApplicable to further painting

    Surface treatment of hot dip galvanized steel sheet and coil

    ItemDescription
    Chromate treatment (L)Chromate treatment is a chemical treatment with an aim to prevent white rusts formed on product surfaces during transportation and storage.
    Oiling (Y)Oiling is to prevent white rusts formed on product surfaces during transportation and storage.
    Chromate treatment+ Oiling (LY)Chromate treatment+ Oiling (LY) This treatment with oiling after surface chromate treatment is to further avoid the forming of white rusts.

    JIS G 3302 galvanized steel sheet chemical composition

    GradeChemical Composition.% Max
    CMnPS
    SGHC0.150.80.050.05
    SGHC4000.251.70.20.05
    SGHC4400.2520.20.05
    SGHC4900.320.20.05
    SGHC5400.32.50.20.05
    SGCC0.150.80.050.05
    SGCH0.181.20.080.05
    SGCD10.120.60.040.04
    SGCD20.10.450.030.03
    SGCD30.080.450.030.03
    SGCD40.060.450.030.03
    SGC3400.251.70.20.05
    SGC4000.251.70.20.05
    SGC4400.2520.20.05
    SGC4900.320.20.05
    SGC5700.32.50.20.05

    Applications of hot dip galvanized steel sheet and coil

    • Automotive
    • Pipe and Tub
    • Outdoor Recr
    • Agriculture
    • Construction

    Advantage of hot dip galvanized steel sheet and coil

    • Superior Formability
    • Excellent Corrosion Resistance
    • Consistent Quality

    Standard Specifications hot dip galvanized steel sheet and coil

    • ASTM A 653 hot-dipped galvanized carbon steel sheet
    • ASTM A 1003 hot-dipped galvanized carbon steel sheet for cold-formed framing members
    • SAE J1392 hot-dipped galvanized, high-strength, low-allow carbon steel sheet
    • SAE J403 hot-dipped galvanized carbon sheet steel
    • ASTM A929 hot-dipped galvanized steel sheet for corrugated steel pipe
    • Additional JIS, DIN, and manufacturer-specific standards available on an inquiry-by-inquiry basis.
