    Red Color Z225 0.75*1220 PPGI Pre Paint Steel Coils HDP S320GD European Standard EN10169

    Ask Lasest Price
    Brand Name : Decho Building Materials
    Model Number : S320GD PRE-PAINTED GAVANIZED STEEL
    Certification : MILL TEST CERTIFICATE
    Price : USD 780~1050
    Payment Terms : L/C, T/T
    Supply Ability : 500 tons per day
    Delivery Time : 30~45days
    • Product Details
    • Company Profile

    Red Color Z225 0.75*1220 PPGI Pre Paint Steel Coils HDP S320GD European Standard EN10169

    Red Color Z225 0.75*1220 PPGI Pre-Paint Steel Coils HDP S320GD European Standard EN10169


    Product details:

    PPGL, also known as coated laminated coil or color-coated laminated coil, is a flat steel product with a protective decorative coating. The polymer coating is available in a wide range of colors, matte, glossy or with natural decorative finishes (granite, wood, etc.). Organically coated galvanized steel is corrosion-resistant, has excellent mechanical properties and can be formed, pressed or stamped.


    HDP High Weather Resistant Color Coated Sheet adopts HDP polyester coating with good durability, adopts high molecular weight resin, with less polymer branched chain, stable bonding, not easy to photolysis, so it is not easy to chalking and high gloss. The main performance of high weathering polyester is strong weather resistance and corrosion resistance, mainly used for long sunshine time, high dryness, or large temperature difference between day and night, strong humidity and other harsh areas, wide range of uses.


    Application areas:

    Building sector: for the manufacture of exterior and interior products such as metal sheets, corrugated sheets, sandwich panels, profiles, metal ceilings, skirting boards, decorative panels in heated and unheated facilities, lifts, doors, window shutters, shelves, etc.


    Automotive industry: for the manufacture of exterior and interior car body parts (car doors, car shoes, oil filters, dashboards, wipers, etc.)


    Manufacture of household appliances, furniture, and consumer goods: metal furniture, light fixtures, shelving, radiators, car doors, car boots, etc.


    PPGL is widely used in construction, civil engineering, and decoration of columns and beams. Color corrugated sheets are durable, easy to use, and aesthetically pleasing. PPGL can keep buildings, cars, and appliances in perfect condition for years.


    Steel Grade:

    EN10346-DX51D/ DX52D/ DX53D, S250GD/280GD/350GD/550GD, ASTM A527M, CS-B, SS255-SS550


    Paint Brand:

    Valpar, AkzoNobel, PPG, Beckers, Chinese Local Paint Brand


    Paint Coating Patterns:

    Gloss Colors - RAL Code


    Thickness
    GI 0.20mm~1.70mm GL 0.20mm~3.0mm
    Width
    600mm~1500mm
    Zink-Coating
    Z40~Z275g/㎡ AZ30~AZ200g/㎡
    Paint Structure
    2/1, 2/2, 3/2, 3/3
    Paint Coating
    Top side 15μm~55μm Back side 5μm~30μm

    Structural GradesCMnPSAlSiCuNiCrMoVCbTiN
    30,33,36,400.250.90.0350.040.20.20.150.060.0080.0080.025
    36T2,45-800.251.350.0350.040.20.20.150.060.0080.0080.025
    45T2.02- 0.08.30- 1.0.03- .070.025.02- .080.60.20.20.150.060.0080.0080.025.01- .03

    HSLA GradesCMnPSAlSiCuNiCrMoVCbTiN
    45C10.221.350.040.040.20.20.150.060.0050.0050.005
    45C20.151.350.040.040.20.20.150.060.0050.0050.005
    50C10.231.350.040.040.20.20.150.060.0050.0050.005
    50C2 & 55C20.151.350.040.040.20.20.150.060.0050.0050.005
    55C10.251.350.040.040.20.20.150.060.0050.0050.005
    60C1 & 65C10.261.50.040.040.20.20.150.060.0050.0050.005
    60C2 & 65C20.151.50.040.040.20.20.150.060.0050.0050.005
    70C10.261.650.040.040.20.20.150.160.0050.0050.005
    70C20.151.650.040.040.20.20.150.160.0050.0050.005

    Common GradesCMnPSAlSiCuNiCrMoVCbTiN
    CSA0.10.60.030.0350.20.20.150.060.0080.0080.025
    CSB0.02-.150.60.030.0350.20.20.150.060.0080.0080.025
    CSC0.080.60.10.0350.20.20.150.060.0080.0080.025
    BH0.0121.50.120.030.20.20.150.060.0080.0080.025
    FSA0.10.50.020.0350.20.20.150.060.0080.0080.025
    FSB0.02-.150.50.020.030.20.20.150.060.0080.0080.025
    DDS0.060.50.020.025.010.20.20.150.060.0080.0080.025
    EDDS0.020.40.020.02.01*0.20.20.150.060.10.10.15
